Box: 18 mm multi-layer board with internal reinforcement. Surface treatment: the standard color is black, steel sand spraying process. Protective grating: 1.5mm sound permeable steel plate. Frequency divider: built in passive frequency divider network, modular design.
Box: 18mm multilayer board with internal reinforcement
Surface treatment: the standard color is black, steel sand spraying process
Protective grating: 1.5mm sound permeable steel plate
Frequency divider: built in passive frequency divider network, modular design
Lifting point: professional aluminum Pendant
Input connection point: 2 nextrik speakon nl4mp & nbsp; speaker connectors
Unit composition: bass unit: 2 * 8" Voice-coil :51mm Treble unit:1*1.5"Voice-coil:76mm | Frequency response (+/-3dB)65--18 000Hz |
Coverage angle（-6dB):100 degrees (horizontal) * 10 degrees (vertical) | Sensitivity：100dB@1W.M |
Maximum sound pressure level：129dB | Standard impedance: 8 ohm |
Input power: 450 W (rated) 1800 w (peak) | Net size（H * W *D）：260mm*710mm*400mm |
Net weight：（KG）：25 |
