Box: 15mm multilayer board with internal reinforcement. Surface treatment: five layers of water-soluble paint (color can be customized according to customer requirements). Protective grating: 1.5mm sound permeable steel plate. Frequency divider: built in passive frequency divider network, modular design.
Box: 15mm multilayer board with internal reinforcement
Surface treatment: five layers of water-soluble paint covering (color can be customized according to customer requirements)
Protective grating: 1.5mm sound permeable steel plate
Frequency divider: built in passive frequency divider network, modular design
Lifting point: 5-point pre installed hanger, 1 standard 35 mm support base
Input connection point: 2 netrik speakon nl4mp speaker connectors
Unit composition: Bass unit：1*15" Voice-coil :76mm Treble unit：1*1.5"Voice-coil:75mm | Frequency response(+/-3dB):50--20 000Hz |
Coverage angle (- 6dB): 80 degrees (horizontal) * 50 degrees (vertical) | Sensitivity：100dB@1W.M |
Standard impedance: 8 ohm | Input power: 550W (rated) 2200W (peak) |
Net size（H * W *D）：670mm*430mm*470mm | Net weight：（KG）：30 |
