Box: 15mm high density MDF reinforced inside. Surface treatment: five layers of water-soluble paint (color can be customized according to customer requirements). Protective grating: 1.5mm sound permeable steel plate. Frequency divider: built in passive frequency divider network, modular design.
Box: internal reinforced 15 mm high density MDF
Surface treatment: five layers of water-soluble paint covering (color can be customized according to customer requirements)
Protective grating: 1.5mm sound permeable steel plate
Frequency divider: built in passive frequency divider network, modular design
Lifting point: 5-point pre installed hanger, 1 standard 35 mm support base
Input connection point: 2 netrik speakon nl4mp speaker connectors
Unit composition: Bass unit：1*10" Voice-coil :65mm Treble unit：1*1"Voice-coil:44.4mm | Frequency response(+/-3dB):60--18 000Hz |
Coverage angle (- 6dB): 90 degrees (horizontal) * 60 degrees (vertical) | Sensitivity：91dB@1W.M |
Sound pressure output: 118db (rated) / 123dB (peak value) | Standard impedance: 8 ohm |
Input power: 250W (rated) 1000W (peak) | Net size（H * W *D）：490mm*315mm*330mm |
Net weight：（KG）：16 |
